Product Introduction
Product Introduction:50mm T30 Torx Impact Bit for Efficient Fastening
The Ultra-Torque T30 Torx impact driver bit combines a 50mm length with a precision-machined T30 tip for fastening applications that use T30 Torx screws. Its color-coded finish makes the size easier to identify in a toolbox or on a production line, helping reduce time spent searching for the correct bit.Made from S2 alloy steel and heat-treated to HRC 60, the bit is built for repeated use with compatible impact drivers. The torsion zone helps absorb rotational shock during fastening, while the black manganese phosphate finish provides surface protection. A magnetic tip helps hold screws during positioning and installation.GEINXURN supplies impact driver bits for distributors, wholesalers and tool brands. Contact us to confirm available shank options, packaging, customization and order requirements for this T30 model.
Features:
- T30 Torx tip: Designed for fasteners with a T30 Torx recess.
- 50mm overall length: Provides additional reach compared with a standard 25mm bit.
- Color-coded identification: Helps users distinguish bit sizes quickly.
- S2 alloy steel: Heat-treated to HRC 60, according to the product specifications.
- Torsion zone: Helps absorb impact forces during fastening.
- Magnetic tip: Helps retain screws during handling and installation.
- Protective surface finish: Manganese phosphate coating helps protect the bit surface.
Applications:
- Automotive maintenance: For assembly and repair tasks using T30 Torx fasteners.
- Equipment assembly: For fastening applications in machinery and industrial equipment.
- Construction and installation: For compatible T30 Torx screws in suitable materials.
- Production and workshop use: Color coding can make bit selection easier during repetitive work.
- General repair: Suitable for users who need a 50mm T30 bit for compatible fastening jobs.
| Size | Code | Material | HRC | Shank Size | Tip Diameter（mm） | Length（mm） | EU or US |
| T7 T8 T9 T10 T15 T20 T25 T27 T30 T40 |
BTXT2025-UT | S2 Alloy Steel | 60 | 1/4" | 2.6-2.9 | 25 | ALL |
| BTXT8025-UT | S2 Alloy Steel | 60 | 1/4" | 2.8-3.0 | 25 | ALL | |
| BTXT9025-UT | S2 Alloy Steel | 60 | 1/4" | 3.1-3.3 | 25 | ALL | |
| BTXT10025-UT | S2 Alloy Steel | 60 | 1/4" | 3.3-3.6 | 25 | ALL | |
| BTXT15025-UT | S2 Alloy Steel | 60 | 1/4" | 3.8-4.1 | 25 | ALL | |
| BTXT20025-UT | S2 Alloy Steel | 60 | 1/4" | 4.5-5.0 | 25 | ALL | |
| BTXT25025-UT | S2 Alloy Steel | 60 | 1/4" | 5.0-5.5 | 25 | ALL | |
| BTXT27025-UT | S2 Alloy Steel | 60 | 1/4" | 5.5-6.0 | 25 | ALL | |
| BTXT30025-UT | S2 Alloy Steel | 60 | 1/4" or 5/16" | 6.2-6.5 | 25 | ALL | |
| BTXT40025-UT | S2 Alloy Steel | 60 | 5/16" | 7.5-8.0 | 25 | ALL | |
| T7 T8 T9 T10 T15 T20 T25 T27 T30 T40 |
BTXT7050-UT | S2 Alloy Steel | 60 | 1/4" | 2.6-2.9 | 50 | ALL |
| BTXT8050-UT | S2 Alloy Steel | 60 | 1/4" | 2.8-3.0 | 50 | ALL | |
| BTXT9050-UT | S2 Alloy Steel | 60 | 1/4" | 3.1-3.3 | 50 | ALL | |
| BTXT10050-UT | S2 Alloy Steel | 60 | 1/4" | 3.3-3.6 | 50 | ALL | |
| BTXT15050-UT | S2 Alloy Steel | 60 | 1/4" | 3.8-4.1 | 50 | ALL | |
| BTXT20050-UT | S2 Alloy Steel | 60 | 1/4" | 4.5-5.0 | 50 | ALL | |
| BTXT25050-UT | S2 Alloy Steel | 60 | 1/4" | 5.0-5.5 | 50 | ALL | |
| BTXT27050-UT | S2 Alloy Steel | 60 | 1/4" | 5.5-6.0 | 50 | ALL | |
| BTXT30050-UT | S2 Alloy Steel | 60 | 1/4" or 5/16" | 6.2-6.5 | 50 | ALL | |
| BTXT40050-UT | S2 Alloy Steel | 60 | 5/16" | 7.5-8.0 | 50 | ALL | |
| T7 T8 T9 T10 T15 T20 T25 T27 T30 T40 |
BTXT7075-D2UT | S2 Alloy Steel | 60 | 1/4" | 2.6-2.9 | D2-75 | ALL |
| BTXT8075-D2UT | S2 Alloy Steel | 60 | 1/4" | 2.8-3.0 | D2-75 | ALL | |
| BTXT9075-D2UT | S2 Alloy Steel | 60 | 1/4" | 3.1-3.3 | D2-75 | ALL | |
| BTXT10075-D2UT | S2 Alloy Steel | 60 | 1/4" | 3.3-3.6 | D2-75 | ALL | |
| BTXT15075-D2UT | S2 Alloy Steel | 60 | 1/4" | 3.8-4.1 | D2-75 | ALL | |
| BTXT20075-D2UT | S2 Alloy Steel | 60 | 1/4" | 4.5-5.0 | D2-75 | ALL | |
| BTXT25075-D2UT | S2 Alloy Steel | 60 | 1/4" | 5.0-5.5 | D2-75 | ALL | |
| BTXT27075-D2UT | S2 Alloy Steel | 60 | 1/4" | 5.5-6.0 | D2-75 | ALL | |
| BTXT30075-D2UT | S2 Alloy Steel | 60 | 1/4" or 5/16" | 6.2-6.5 | D2-75 | ALL | |
| BTXT40075-D2UT | S2 Alloy Steel | 60 | 5/16" | 7.5-8.0 | D2-75 | ALL | |
| T7 T8 T9 T10 T15 T20 T25 T27 T30 T40 |
BTXT7150-D2UT | S2 Alloy Steel | 60 | 1/4" | 2.6-2.9 | D2-150 | ALL |
| BTXT8150-D2UT | S2 Alloy Steel | 60 | 1/4" | 2.8-3.0 | D2-150 | ALL | |
| BTXT9150-D2UT | S2 Alloy Steel | 60 | 1/4" | 3.1-3.3 | D2-150 | ALL | |
| BTXT10150-D2UT | S2 Alloy Steel | 60 | 1/4" | 3.3-3.6 | D2-150 | ALL | |
| BTXT15150-D2UT | S2 Alloy Steel | 60 | 1/4" | 3.8-4.1 | D2-150 | ALL | |
| BTXT20150-D2UT | S2 Alloy Steel | 60 | 1/4" | 4.5-5.0 | D2-150 | ALL | |
| BTXT25150-D2UT | S2 Alloy Steel | 60 | 1/4" | 5.0-5.5 | D2-150 | ALL | |
| BTXT27150-D2UT | S2 Alloy Steel | 60 | 1/4" | 5.5-6.0 | D2-150 | ALL | |
| BTXT30150-D2UT | S2 Alloy Steel | 60 | 1/4" or 5/16" | 6.2-6.5 | D2-150 | ALL | |
| BTXT40150-D2UT | S2 Alloy Steel | 60 | 5/16" | 7.5-8.0 | D2-150 | ALL |
Consistent product specifications: Clear size, material and hardness information helps buyers evaluate the bit for their applications.
Color-coded identification: Helps users quickly distinguish bit sizes during workshop and production-line tasks.
Manufacturer and supplier support: GEINXURN works with distributors, wholesalers and tool brands on product sourcing.
Wholesale and OEM inquiries: Contact us to discuss available models, packaging and customization requirements.
Responsive sales assistance: Our team can help confirm specifications and provide information for your order.
Q: What is a T30 Torx impact driver bit used for?
A T30 bit is used with screws that have a matching T30 Torx recess. Check the fastener size before use to help ensure a proper fit.
Q: What is the length of this GEINXURN T30 bit?
This model is listed as 50mm, or approximately 2 inches long.
Q: What material is the bit made from?
The product specifications list S2 alloy steel with a hardness of HRC 60.
Q: Is this bit compatible with impact drivers?
It is designed for use with compatible impact drivers. Confirm the shank type and driver compatibility before ordering.
Q: Can I order this model for wholesale or OEM projects?
GEINXURN invites wholesale and OEM inquiries. Contact the sales team to confirm order quantities, packaging and customization options.
Request a Quote for 50mm T30 Torx Impact Driver Bits
Looking for a color-coded T30 impact driver bit for your product range or purchasing program? Contact GEINXURN to discuss specifications, packaging and wholesale or OEM requirements.
